| Frame/Housing: | Plastic | ||||||||||||||
| Impeller: | Plastic | ||||||||||||||
| Bearing System: | Ball bearing | ||||||||||||||
| Motor: | Capacitor run motor | ||||||||||||||
| Connection: | Lead wire or termnal type | ||||||||||||||
| Protection: | Thermally-Protected | ||||||||||||||
| Insulation Resistance: | Above 100MΩ,DC 500V. | ||||||||||||||
| Life Expectancy: | Over 40,000 hrs.(at 40°C) | ||||||||||||||
| Safety Approval: | CE | ||||||||||||||
| Description of Model No. |
|
| DF200P23-H | DF200P23-L | |||
|---|---|---|---|---|
| Rated Voltage | 230 V | 230 V | ||
| Frequency | 50 Hz | 50 Hz | ||
| Input Power | 150 W | 125 W | ||
| Rated Current | 0.63 A | 0.54 A | ||
| Locked Current | 0.95 A | 0.65 A | ||
| Speed | 2100 RPM | 170 RPM | ||
| Maximum Air Flow | 15.6 m3/min. | 12.5 m3/min. | ||
| Maximum Air Flow | 550 CFM | 440 CFM | ||
| Maximum Pressure | 29 mmH2O | 26 mmH2O | ||
| Maximum Pressure | 1.14 InchH2O | 1.02 InchH2O | ||
| Noise | 59 dB | 53 dB | ||
| Weights | 4 kg | 4 kg |
