Centrifugal Fan

UF220APA Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Shaded pole or capacitor start-run
Protection: Impedance-Protected or Thermally-Protected or Electronically-Protected
Insulation Resistance: Above 100MΩ, DC500V.
Dielectric withstand voltage AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 40,000 hr. (at 40℃)
Safety Approval: CUL, CE, TUV, either UL or ETL.
Description of Model No.
UF 190 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10





Get Latest Price
UF220APA11H2C2A UF220APA23H2C2A
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 90/117 W 90/117 W
Rated Current 0.63/0.8 A 0.35/0.39 A
Locked Current 0.88/0.93 A 0.47/0.49 A
Speed 2500/2650 RPM 2500/2650 RPM
Maximum Air Flow 14/15 m3/min. 14/15 m3/min.
Maximum Air Flow 500/530 CFM 500/530 CFM
Maximum Pressure 35/38 mmH2O 35/38 mmH2O
Maximum Pressure 1.4/1.7 InchH2O 1.4/1.7 InchH2O
Noise 65/70 dB 65/70 dB
Weights 1.5 kg 1.5 kg
