UFT60BBPB Series

UFT60BBPB Series

UFT60BBPB Series

EC fan

UFT60BBPB Series

Frame/Housing:

Aluminum die-casting

Impeller:

Plastic or steel

Bearing System:

Ball bearing

Motor:

Brushless DC motor

Protection:

Electronically-Protected

Insulation Resistance:

Above 10MΩ, DC500V

Dielectric withstand voltage:

AC 1,500V (50/60Hz) one minute

Life Expectancy:

Ball bearing: Over 50,000 hr. (at 40℃)

Safety Approval:

UL .TUV. CE .

Description of Model No.

UF	220	A	P	A	11	H1	C	2	A
1	2	3	4	5	6	7	8	9	10

Get Latest Price

	UFT60BBPB0A M1D4A
Rated Voltage	115~230 V
Frequency	50/60 Hz
Input Power	2.0(115V) 2.3(230V) W
Rated Current	0.039(115V) 0.025(230V) A
Locked Current	0.092(115V) 0.044(230V) A
Speed	3850(115V) 3950(230V) RPM
Maximum Air Flow	0.0.54(115V) 0.55(230V) m3/min.
Maximum Air Flow	19.1(115V) 19.4(230V) CFM
Maximum Pressure	4.3(115V) 4.6(230V) mmH2O
Maximum Pressure	0.0.17(115V) 0.18(230V) InchH2O
Noise	31 dB
Weights	0.06 kg

SAFETY APPROVAL
