Axial Fan

UF15KME Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF15KME11-H UF15KME23-H
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 42/42 W 42/42 W
Rated Current 0.51/0.46 A 0.25/0.23 A
Locked Current 0.87/0.74 A 0.43/0.37 A
Speed 2800/3250 RPM 2800/3250 RPM
Maximum Air Flow 5.5/6.5 m3/min. 5.5/6.5 m3/min.
Maximum Air Flow 195/230 CFM 195/230 CFM
Maximum Pressure 14/16 mmH2O 14/16 mmH2O
Maximum Pressure 0.55/0.63 InchH2O 0.55/0.63 InchH2O
Noise 45/50 dB 45/50 dB
Weights 0.91 kg 0.91 kg
