Axial Fan

UF15PE Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF15PE11 UF15PE23
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 36/33 W 36/33 W
Rated Current 0.51/0.42 A 0.24/0.2 A
Locked Current 0.62/0.54 A 0.29/0.25 A
Speed 2650/2950 RPM 2650/2950 RPM
Maximum Air Flow 4.53/5.1 m3/min. 4.53/5.1 m3/min.
Maximum Air Flow 160/180 CFM 160/180 CFM
Maximum Pressure 4.06/4.57 mmH2O 4.06/4.57 mmH2O
Maximum Pressure 0.16/0.18 InchH2O 0.16/0.18 InchH2O
Noise 48/53 dB 48/53 dB
Weights 0.78 kg 0.78 kg
SAFETY APPROVAL
