EC fan

UFT200BPB

Frame/Housing: Aluminum die-casting
Impeller: Plastic or steel
Bearing System: Ball bearing
Motor: Brushless DC motor
Protection: Electronically-Protected
Insulation Resistance: Above 10MΩ, DC500V
Dielectric withstand voltage: AC 1,500V (50/60Hz) one minute
Life Expectancy: Ball bearing: Over 50,000 hr. (at 40℃)
Safety Approval: UL .TUV. CE .
Description of Model No.
UF 220 A P A 11 H1 C 2 A
1 2 3 4 5 6 7 8 9 10





Get Latest Price
UFT200BPB11H1D4A UFT200BPB11H1D4A UFT200BPB23H1D4A
Rated Voltage 115V 115V 230V
Frequency 50/60 50/60 50/60
Input Power 26 8.1 27
Rated Current 0.4 0.13 0.24
Locked Current 0.10 0.10 0.20
Speed 2200 1400 2200
Maximum Air Flow 14 8.9 14
Maximum Air Flow 495 315 495
Maximum Pressure 14.0 8.1 14.0
Maximum Pressure 0.55 0.32 0.55
Noise 56 47 56
Weights 0.92kg 0.92kg 0.92kg
SAFETY APPROVAL
