Axial Fan

UF25GCE Series

Frame/Housing: Aluminum die-casting
Impeller: Plastic PBT PC,nylon or metal
Bearing System: Ball bearing or sleeve bearing
Motor: Shaded pole or capacitor start-run
Connection: Lead wire or termnal type
Protection: Impedance-Protected or Thermally-Protected
Dielectric withstand voltage: Above 10MΩ, DC500V
Life Expectancy: Ball bearing:Over 40,000 hr.(at 40°C)
Sleeve bearing:Over 15,000 hr.(at 40°C)
Safety Approval: CUL, CE, TUV, either UL or ETL
Description of Model No.
UF 12 A (R) 11 B T H N
1 2 3 4 5 6 7 8 9


Get Latest Price
UF25GCE11-H UF25GCE23-H
Rated Voltage 115 V 230 V
Frequency 50/60 Hz 50/60 Hz
Input Power 36/39 W 36/39 W
Rated Current 0.3/0.29 A 0.14/0.14 A
Locked Current 0.53/0.51 A 0.26/0.25 A
Speed 1400/1650 RPM 1400/1650 RPM
Maximum Air Flow 13/15.5 m3/min. 13/15.5 m3/min.
Maximum Air Flow 460/550 CFM 460/550 CFM
Maximum Pressure 8/10 mmH2O 8/10 mmH2O
Maximum Pressure 0.32/0.4 InchH2O 0.32/0.4 InchH2O
Noise 52/55 dB 52/55 dB
Weights 1.4 kg 1.4 kg
SAFETY APPROVAL
